Concrete Vibrating Screed

  • Name: Concrete Level Ruler
  • Application: Building
  • Fueltype: Four-stroke gasoline engine
  • Driving method: Flexible shaft drive
  • Dry length: 1/6m (standard 2 meters)
  • Product power: 1.2-1.6HP
  • Material: Aluminum
  • Color: Customer Required
Share with:
  • Product Overview
  • Technical parameters
  • Inquiry
Vibration Ruler

Details:

Concrete Vibration Ruler Screed Machine Road Construction Machinery.Concrete screed ruler could be easily operated and greatly increases work efficiency for reducing air voids and enhancing concrete compaction.

Mainly be used for scraping of concrete ground surface, improve the density of concrete, suitable for leveling hardening of the ground. High speed and efficiency, easy for take. Strickling and vibrating finish together. Operator can adjust the impact force at any moment, manual accelerator controls vibrating frequency.Concrete surface after vibration, no need to sprinkle dry cement when press polish. It reduce the construction cost and repair frequency greatly.


Gasoline Vibration Ruler

Product number

Semi-aluminum gasoline

Aluminum alloy vibration ruler

Gasoline

Configuration power

G*35 Gasoline Engine

G*35 Gasoline Engine

G*35 Gasoline Engine

Fuel type

Four-stroke gasoline engine

Four-stroke gasoline engine

Four-stroke gasoline engine

Oil capacity

0.7L

0.7L

0.7L

Product power consumption

1.2-1.6HP

1.2-1.6HP

1.2-1.6HP

Rated speed

5200r/min

5200r/min

5200r/min

Driving method

Flexible shaft drive

Flexible shaft drive

Flexible shaft drive

Vibration frequency

9500 times/min

9500 times/min

9500 times/min

Dry length

1/6m (standard 2 meters)

1/6m (standard 2 meters)

1/6m (standard 2 meters)

Warranty time

1 year warranty

1 year warranty

1 year warranty

Machine quality

28KG

25KG

25KG


Feature:

1.High speed and efficiency,easy for take.Strickling and vibrating finish together.
2.Operator can adjust the impact force at any moment, manual accelerograph controls vibrating frequency.
3.Concrete surface after vibration,no need to sprinkle dry cement when press polish. It reduce the construction cost and repair frequency greatly.

4.Suitable for flat cement and concrete surface during construction building site androad construction and so on.
5.Can avoid situation as concrete surface empty,knob and split completely which usually appear after concrete surface

constructing. Finish the firmly,solid and close-graind concrete surface.


Purpose:

It is used to exhaust air from concrete, scrape the concrete floor and enhance the density of concrete.

1. Replacing the two working procedures of roller and scraper in the traditional construction technology, reducing the cost and improving the efficiency

2. The machine body is made of durable aluminum alloy materials. The whole machine is light, easy and safe to use and has high flatness.

3. Aluminum alloy blades are durable and have high flatness.

4. The height of the handle can be adjusted, which is suitable for operators of different heights.

Gasoline Vibration Ruler

Product number

Semi-aluminum gasoline

Aluminum alloy vibration ruler

Gasoline

Configuration power

G*35 Gasoline Engine

G*35 Gasoline Engine

G*35 Gasoline Engine

Fuel type

Four-stroke gasoline engine

Four-stroke gasoline engine

Four-stroke gasoline engine

Oil capacity

0.7L

0.7L

0.7L

Product power consumption

1.2-1.6HP

1.2-1.6HP

1.2-1.6HP

Rated speed

5200r/min

5200r/min

5200r/min

Driving method

Flexible shaft drive

Flexible shaft drive

Flexible shaft drive

Vibration frequency

9500 times/min

9500 times/min

9500 times/min

Dry length

1/6m (standard 2 meters)

1/6m (standard 2 meters)

1/6m (standard 2 meters)

Warranty time

1 year warranty

1 year warranty

1 year warranty

Machine quality

28KG

25KG

25KG
