1.Adopt modular structure, installation and relocation is very convenient.
2.Using JS double shaft concrete mixer with PLD series concrete batching machine, accurate measurement and mixing of good quality and high production efficiency.
3.It can produce various kinds of concrete including quaking concrete and hard concrete, with high produce efficiency,
4.The overall structure is compact and fashionable, the layout is reasonable
5.The operation is safe and reliable, its more easy to maintain
3.Research and development
|
Model |
HZS60 |
HZS90 |
HZS120 |
HZS180 |
|
|
Mixing Plant |
Theoretical productivity |
60m3/h |
90m3/h |
120m3/h |
180m3/h |
|
Discharging Height |
4.2m |
4.2m |
4.2m |
4.2m |
|
|
Installation Capability |
108.8kw |
153.5kw |
213kw |
264kw |
|
|
Mixing System |
Mixer Model |
JS1000 |
JS1500 |
JS2000 |
JS3000 |
|
Power |
37kw |
2*30kw |
74.9 |
110.9 |
|
|
Charge Capacity |
1600L |
2400L |
3200L |
4200L |
|
|
Discharge Capacity |
1000L |
1500L |
2000L |
3000L |
|
|
Material Diameter (pebble/gravel) |
60-80mm |
60-80mm |
60-80mm |
60-80mm |
|
|
Aggregate Batching System |
Batching machine Model |
PLD2400-II |
PLD3200-I |
PL3200 |
PL4800 |
|
Storage Hopper Capacity |
3*12m3 |
4*15m3 |
4*18m3 |
4*25m3 |
|
|
Accuracy |
±2% |
4*2.4m3 |
4*3.2m3 |
4*4.8m3 |
|
|
Powder Storage System |
Detachable Silo Model |
2*100/160T |
3*100T |
4*100T |
4*200T |
|
Conveying System |
Screw Conveyor Model |
LSY219 |
LSY273 |
LSY273-12 |
LSY273-12 |
|
Size(Diameter*Length) |
219mm*9m |
LSY273 |
LSY273-12 |
LSY273-12 |
|
|
Belt Conveyor Model |
B800 |
B800 |
B1000 |
B1200 |
|
|
Size(Width*Length) |
800mm* 3500mm |
800mm* 4200mm |
1000mm* 4500mm |
1200mm* 4500mm |
|
|
Weighing System |
Cement Scales |
600kg |
800kg |
1200kg |
1800kg |
|
Water Scales |
300kg |
400kg |
500kg |
700kg |
|
|
Additive Scales |
30kg |
70kg |
70kg |
70kg |
|
|
Fly ash Scales |
400kg |
400kg |
500kg |
850kg |
|
|
Measurement Precision |
±1% |
±1% |
±1% |
±1% |
|
|
Air Supply System |
Air Compressor |
||||
|
Electric Control System |
PLC control system,control console,weak&heavy current regulator |
||||
Packing & Delivery
| Packaging Details: | Standard Exporting package |
| Delivery Detail: | 15days |
|
